Dome-Type Indoor CCTV Camera
The Dome-Type Indoor CCTV Camera is designed for reliable, discreet, and high-quality video surveillance in indoor environments such as offices, stores, banks, and residential spaces.
With its compact dome design, it blends seamlessly with modern interiors while delivering clear HD or Full HD video, wide-angle coverage, and night vision performance.
Available in analog, AHD, or IP (network) formats, this camera offers flexible integration with existing security systems and ensures 24/7 monitoring with motion detection and remote viewing capabilities.
| Specification | Details |
|---|---|
| Camera Type | Dome-type Indoor CCTV |
| Image Sensor | 1/2.7” CMOS (2MP / 4MP / 5MP options) |
| Resolution | 1080p / 4MP / 5MP HD |
| Lens Type | Fixed 3.6 mm or Varifocal 2.8–12 mm |
| View Angle | 85° – 110° (depending on lens) |
| Video Output | AHD / TVI / CVI / CVBS or IP (optional models) |
| IR Night Vision | 15 – 30 meters (Smart IR LEDs) |
| Day/Night Mode | Auto (ICR Filter) |
| Frame Rate | Up to 25/30 fps |
| Audio Function | Built-in microphone (optional) |
| Power Supply | DC 12 V ± 10% / PoE (for IP models) |
| Power Consumption | < 5 W |
| Operating Temperature | −10 °C ~ +50 °C |
| Material / Housing | ABS / Metal Dome (indoor rated) |
| Mounting Type | Ceiling / Wall mount |
| Protection Rating | IP 40 (indoor use) |
| Dimensions | Approx. Ø 110 × 90 mm |
| Weight | ~250 g |
-
Compact dome design for discreet and stylish indoor installation.
-
High-definition video output with wide dynamic range for clear images.
-
Infrared night vision for 24-hour surveillance.
-
Auto white balance and digital noise reduction (DNR) for improved clarity.
-
Supports motion detection, privacy masking, and image mirroring.
-
Compatible with DVR / NVR / hybrid recorders.
-
Easy ceiling or wall installation with adjustable 3-axis bracket.
-
Available in analog or IP network versions for flexible system setup.
-
Ideal for offices, banks, schools, stores, warehouses, and other indoor sites.
